P Level Sp Level High Quality Linear Guides Guideway Rails Pek Brand Sliding Rail Guide 15mm 20mm 25mm 30mm 35mm Width in Promotion

P Level SP Level High Quality Linear Guides Guideway Rails PEK brand Sliding Rail Guide 15mm 20mm 25mm 30mm 35mm Width i

Send to us

Basic Info

Model NO.	HGR15 HGR20 HGR25 HGR30 HGR35 HGR45
Running Mode	Moving
Feature	Insulating, Antiseptic, Smooth and Durable Linear Rail Slide Guide
Certification	CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
Product Name	Linear Guide
Place of Origin	Shandong, China
Type	Square/Flanged
Length	Customized
Warranty	1.5years
Performance	Anti-Friction, Interchangeable and Lo
Service	OEM
Samples	Provide
Delivery Time	Within 15 Working Days
Packaging	Export Standard Packaging
Brand Name	Pek
Color	Black or Customized
MOQ	1
Used for	CNC Machine, Grinding Machine, Milling Machines, L
Seaport	Qingdao , Shanghai
Transport Package	Export Standard Packaging
Specification	Bearing steel / stainless steel as materials
Trademark	PEK
Origin	Jinan, China
Production Capacity	50000PCS/Month

Product Description

P Level SP Level High Quality Linear Guides Guideway Rails PEK brand Sliding Rail Guide 15mm 20mm 25mm 30mm 35mm Width in Promotion

Description of PEK brand CNC linear guide rail

The design of the JINGRUI linear guide offers easy installation and minimal maintenance with the lowest installed cost in its class. All components are in standard lengths or cut into to your desired lengths as part of a complete assembly.

P Level Sp Level High Quality Linear Guides Guideway Rails Pek Brand Sliding Rail Guide 15mm 20mm 25mm 30mm 35mm Width in Promotion

Specification of SDS Series(High Assembly) C type,ACL type,AC type
Model	Physical Dimension			Block Dimension
Model	Height M	Width W	Length L	B	C	Ø	M	L1	T	T1	K	N	E	Grease Nipple Specification
SDS15C/SDS15AC	24	47	61.8	38	30	4.5	M5	39.8	8.5	7	19.8	4.3	5.5	G-M4
SDS20C/SDS20AC	30	63	77.4	53	40	6	M6	50.8	10	10	25.2	5	12	G-M6
SDS20ACL	30	63	93.4	53	40	6	M6	66.8	10	10	25.2	5	12	G-M6
SDS25C/25AC	36	70	83.5	57	45	7	M8	59.5	16	10	29.25	6	12	G-M6
SDS25ACL	36	70	102.6	57	45	7	M8	78.6	16	10	29.25	6	12	G-M6
SDS30C/SDS30AC	42	90	100.5	72	52	9	M10	70.5	18	10	34.25	7	12	G-M6
SDS30ACL	42	90	123	72	52	9	M10	93	18	10	34.25	7	12	G-M6
SDS35C/SDS35AC	48	100	113.9	82	62	9	M10	80.5	20	13	38.8	8	12	G-M6
SDS35ACL	48	100	139.2	82	62	9	M10	105.8	20	13	38.8	8	12	G-M6
SDS45C/SDS45AC	60	120	138.5	100	80	11	M12	97.7	22	15	50.9	10	16	G-PT1/8
SDS45ACL	60	120	171	100	80	11	M12	129.8	22	15	50.9	10	16	G-PT1/8
SDS55C/SDS55AC	70	140	163	116	95	14	M14	118	29	17	57	11	16	G-PT1/8
SDS55ACL	70	140	201	116	95	14	M14	156.1	29	17	57	11	16	G-PT1/8
SDS65C/SDS65AC	90	170	186	142	110	16	M16	147	37	23	76	19	16	G-PT1/8
SDS65ACL	90	170	246	142	110	16	M16	206.5	37	23	76	19	16	G-PT1/8
SDS85C/SDS85AC	110	215	247	185	140	18	M20	178.6	55	30	94	23	16	G-PT1/8
SDS85ACL	110	215	303	185	140	18	M20	236	55	30	94	23	16	G-PT1/8

P Level Sp Level High Quality Linear Guides Guideway Rails Pek Brand Sliding Rail Guide 15mm 20mm 25mm 30mm 35mm Width in Promotion

Advantages of Linear Guide Rail:

1. Self-Aligning,Simple Installation, Easy maintenance.

2. Low Noise- Smooth, quiet, high speed operation.

3. Interchangeable between rail and carriages without compromising system accuracy.

4. Design flexibility with multiple carriage styles, sizes, preload and accuracy. Multiple rail accuracy and rail mounting options.

5. Length: can be cut for your requirement.

6. Accuracy: five precision grades : Normal/ High/ Precision/ Senior Precision/ Top Precision.

Packaging & Shipping

Packaging :

1.Export standard carton, wooden box

2. According to customer's special requirements.

Shipping:

1. Small sample is packed by carton box and it is shipped by international express as FedEx,UPS,DHL,TNT etc.

It will save shipment cost for customers .

2. Samples in stock will be delivered within 3 days and customized samples will be delivered within 30 days.

Delivery date for bulk order depends on order quantity.
